Caterpillar C32 C ACERT D01 - IMO Tier II
Key Specifications
-
RATED OUTPUT:1,600 bhp / 1,193 KW / 1,622 mhp
-
RATED SPEED:Max 2,300 rpm
-
DISPLACEMENT:32.1 Litres
-
CYLINDERS:V12
-
BORE & STROKE145mm bore , 162mm stroke
-
EMISSION COMPLIANCE:EU Stage III A , IMO Tier II
C32 C ACERT D01 - IMO Tier II Full Specfications
Engine
-
Model Name:C32 C ACERT D01 - IMO Tier II
-
Range:C32
-
Manufacturer:Caterpillar
Engine description
-
No' of Cylinders:12
Performance data
-
Bore145mm .
-
Stroke162mm .
-
Rotation:CCW(Standard Rotation)
Exhaust
-
Exhaust emissions:IMO Tier II/EU Stage III A
Dimensions
-
Height:1,587mm .
-
Width:1,528mm .
-
Length without gearbox:2,284mm .
-
Total displacement:32 Litres
-
Mass3,248kg
Other
-
In production?Yes
-
Solas Compliance?No
