MTU 16V 2000 M94
Key Specifications
-
RATED OUTPUT:2,600 bhp / 1,939 KW / 2,637 mhp
-
RATED SPEED:Max 2,450 rpm
-
DISPLACEMENT:-
-
CYLINDERS:16
-
BORE & STROKE135mm bore , 156mm stroke
-
EMISSION COMPLIANCE:EU Stage III A , EPA Tier 2 , IMO Tier II
16V 2000 M94 Full Specfications
Engine
-
Model Name:16V 2000 M94
-
Range:Series 2000
-
Manufacturer:MTU
Engine description
-
No' of Cylinders:16
-
Flywheel housing:SAE 0
-
Gearbox model:ZF 3070
Performance data
-
Rated power to DIN ISO:ICFN
-
Bore135mm .
-
Stroke156mm .
Exhaust
-
Exhaust emissions:IMO Tier II/EPA Tier 2/EU Stage III A
Dimensions
-
Height:1,410mm .
-
Width:1,295mm .
-
Length without gearbox:2,315mm .
-
Length with gearbox:3,133mm .
-
Mass3,380kg
Other
-
In production?No
-
Solas Compliance?Yes
Models with the 16V 2000 M94 MTU Engine
In Production
Discontinued
Let us know any corrections or additions.
