MTU 16V 2000 M96L
Key Specifications
-
RATED OUTPUT:2,600 bhp / 1,939 KW / 2,638 mhp
-
RATED SPEED:Max 2,450 rpm
-
DISPLACEMENT:35.7 Litres
-
CYLINDERS:16
-
BORE & STROKE135mm bore , 156mm stroke
-
EMISSION COMPLIANCE:Directive 2013/53/EU , EPA Tier 3 Recreational , IMO Tier II
16V 2000 M96L Full Specfications
Engine
-
Model Name:16V 2000 M96L
-
Range:Series 2000
-
Manufacturer:MTU
Engine description
-
No' of Cylinders:16
-
Flywheel housing:SAE 0
-
Gearbox model:ZF 3070
Performance data
-
Rated power to DIN ISO:ICFN
-
Bore135mm .
-
Stroke156mm .
Exhaust
-
Exhaust emissions:IMO Tier II/EPA Tier 3 Recreational/Directive 2013/53/EU
Dimensions
-
Height:1,453mm .
-
Width:1,293mm .
-
Length without gearbox:2,258mm .
-
Length with gearbox:3,078mm .
-
Total displacement:36 Litres
-
Mass3,450kg
Other
-
In production?Yes
-
Solas Compliance?Yes
