MTU 10V 2000 M96
Key Specifications
-
RATED OUTPUT:1,502 bhp / 1,120 KW / 1,522.88 mhp
-
RATED SPEED:Max 2,450 rpm
-
DISPLACEMENT:22 Litres
-
CYLINDERS:10
-
BORE & STROKE135mm bore , 156mm stroke
-
EMISSION COMPLIANCE:Directive 2013/53/EU , EPA Tier 3 Recreational , IMO Tier II
10V 2000 M96 Full Specfications
Engine
-
Model Name:10V 2000 M96
-
Range:Series 2000
-
Manufacturer:MTU
Engine description
-
No' of Cylinders:10
-
Flywheel housing:SAE 1
-
Gearbox model:ZF 2050
Performance data
-
Rated power to DIN ISO:ICFN
-
Bore135mm .
-
Stroke156mm .
Exhaust
-
Exhaust emissions:IMO Tier II/EPA Tier 3 Recreational/Directive 2013/53/EU
Dimensions
-
Height:1,374mm .
-
Width:1,165mm .
-
Length without gearbox:1,604mm .
-
Length with gearbox:2,159mm .
-
Total displacement:22 Litres
-
Mass2,305kg
Other
-
In production?Yes
-
Solas Compliance?Yes
Models with the 10V 2000 M96 MTU Engine
Discontinued
