MTU 10V 2000 M93
Key Specifications
-
RATED OUTPUT:1,500 bhp / 1,120 KW / 1,520.85 mhp
-
RATED SPEED:Max 2,450 rpm
-
DISPLACEMENT:-
-
CYLINDERS:10
-
BORE & STROKE5.31" bore , 6.14" stroke
-
EMISSION COMPLIANCE:EU Stage III A , EPA Tier 2 , IMO Tier II
10V 2000 M93 Full Specfications
Engine
-
Model Name:10V 2000 M93
-
Range:Series 2000
-
Manufacturer:MTU
Engine description
-
No' of Cylinders:10
-
Cylinder displacement:1 Gallons
-
Flywheel housing:SAE 1
-
Gearbox model:ZF 2000
Performance data
-
Rated power to DIN ISO:ICFN
-
Bore5.31" .
-
Stroke6.14" .
Exhaust
-
Exhaust emissions:IMO Tier II/EPA Tier 2/EU Stage III A
Dimensions
-
Height:48.43" .
-
Width:44.49" .
-
Length without gearbox:60.83" .
-
Length with gearbox:88.78" .
-
Mass4,916.3lbs
Other
-
In production?No
-
Solas Compliance?No
Models with the 10V 2000 M93 MTU Engine
Discontinued
