MTU 12V 2000 M93
Key Specifications
-
RATED OUTPUT:1,800 bhp / 1,340 KW / 1,825.02 mhp
-
RATED SPEED:Max 2,450 rpm
-
DISPLACEMENT:26.8 Litres
-
CYLINDERS:12
-
BORE & STROKE5.31" bore , 6.14" stroke
-
EMISSION COMPLIANCE:EU Stage III A , EPA Tier 2 , IMO Tier II
12V 2000 M93 Full Specfications
Engine
-
Model Name:12V 2000 M93
-
Range:Series 2000
-
Manufacturer:MTU
Engine description
-
No' of Cylinders:12
-
Gearbox model:ZF 2060
Performance data
-
Bore5.31" .
-
Stroke6.14" .
Exhaust
-
Exhaust emissions:IMO Tier II/EPA Tier 2/EU Stage III A
Dimensions
-
Height:53.15" .
-
Width:50.98" .
-
Length without gearbox:73.62" .
-
Length with gearbox:101.57" .
-
Total displacement:7 Gallons
-
Mass6,128.84lbs
Other
-
In production?No
Models with the 12V 2000 M93 MTU Engine
In Production
Discontinued
Let us know any corrections or additions.
