Caterpillar C18 C ACERT A02 - U.S. EPA Tier 3 and IMO Tier II
Key Specifications
-
RATED OUTPUT:600 bhp / 447 KW / 608 mhp
-
RATED SPEED:Max 1,800 rpm
-
DISPLACEMENT:18.1 Litres
-
CYLINDERS:6 In-line
-
BORE & STROKE5.71" bore , 7.2" stroke
-
EMISSION COMPLIANCE:EU Stage III A , EPA Tier 3 , IMO Tier II
C18 C ACERT A02 - U.S. EPA Tier 3 and IMO Tier II Full Specfications
Engine
-
Model Name:C18 C ACERT A02 - U.S. EPA Tier 3 and IMO Tier II
-
Range:C18
-
Manufacturer:Caterpillar
Engine description
-
No' of Cylinders:6
Performance data
-
Bore5.71" .
-
Stroke7.2" .
-
Rotation:CCW(Standard Rotation)
Exhaust
-
Exhaust emissions:IMO Tier II/EU Stage III A/EPA Tier 3
Dimensions
-
Height:51.18" .
-
Width:47.4" .
-
Length without gearbox:76.02" .
-
Total displacement:5 Gallons
-
Mass4,299.01lbs
Other
-
In production?Yes
-
Solas Compliance?No
