Caterpillar C32 ACERT D01 - U.S. EPA Tier 3 and IMO Tier II/III
Key Specifications
-
RATED OUTPUT:1,600 bhp / 1,193 KW / 1,622 mhp
-
RATED SPEED:Max 2,300 rpm
-
DISPLACEMENT:32.1 Litres
-
CYLINDERS:V12
-
BORE & STROKE5.71" bore , 6.38" stroke
-
EMISSION COMPLIANCE:EU Stage III A , EPA Tier 3 Recreational , IMO Tier II
C32 ACERT D01 - U.S. EPA Tier 3 and IMO Tier II/III Full Specfications
Engine
-
Model Name:C32 ACERT D01 - U.S. EPA Tier 3 and IMO Tier II/III
-
Range:C32
-
Manufacturer:Caterpillar
Engine description
-
No' of Cylinders:12
Performance data
-
Bore5.71" .
-
Stroke6.38" .
-
Rotation:CCW(Standard Rotation)
Exhaust
-
Exhaust emissions:IMO Tier II/EU Stage III A/EPA Tier 3 Recreational
Dimensions
-
Height:56.89" .
-
Width:58.35" .
-
Length without gearbox:82.8" .
-
Total displacement:8 Gallons
-
Mass6,779.21lbs
Other
-
In production?Yes
-
Solas Compliance?No
